Restored east masonry wall and replacement outlookers

DeTurk

Images

Description

Restored wall above and to the north of the ground-level DeTurk kitchen door with replacement north hood outlooker. Details include: pegged mortise-and-tenon joint between the doorway lintel and north jamb, checked timber, filleted bead{1} molding on interior edges [“arrises”] of the door jamb and lintel. Final pointing will conceal the end-grain of the "ripped" inch at the bottom of the embedded portion of the outlooker, which is set one-inch above the level of the recent [deflected] height above the doorway lintel in order to level it with the south outlooker, which was lowered one-inch by cutting away ["rip-sawing"] the top inch from its projecting segment and the bottom inch from its embedded segment. The bottom of the projecting portion is now at the same vertical separation [approximately 4"] from the lintel as is the south outlooker [See DTR09PH108--1001.01.204. FOOTNOTE {1} “Rabbet and quarter-round” in a 1797 Chester County carpenter’s pricing guide, which classifies door frames with only this detail as “plain." Larry Ward, 2010

Catalog details

Catalog number
1001.01.212
Alternate number
DTR09PH116
Accession number
1001.01
Date
12/07/2009
Creator
Larry Ward
Object name
Print, Photographic
Record type
Standard
Classification
Documentary Artifact
